DuPont™ Tychem® 10000
TK554T LY

DuPont™ Tychem® 10000 Encapsulated Level A Suit. Expanded Back, Front Entry. Extra-Wide, anti-fog, three-layer faceshield: 40 mil PVC / 5 mil Teflon™ / 20 mil PVC. Attached Dual Layer Gloves, Internal: Multi-layer laminate / External: Butyl. Attached Socks with Outer Boot Flaps. Double Storm Flap with Hook & Loop Closure. Two Exhaust Valves. Double Taped Seams. Lime Yellow.

Fit in a Range

Download Master File

Selling Tips

Media, web, pictures & literature

Request A Sample

Product Info & Wear Trials

Click circles to show off details

More Technical Information and datasheet

Catalogues & Codes

Reference:

Size	D-code
MD MTO	D13490784
MD MTO	D13490793
MD MTO	D13637489
LG MTO	D13490701
LG MTO	D13490699
LG MTO	D13490717
XL MTO	D13490867
XL MTO	D13490885
XL MTO	D13490858
2X MTO	D13490485
2X MTO	D13490500
2X MTO	D13490478
3X MTO	D13490612
3X MTO	D13637263
3X MTO	D13490624
4X MTO	D13637333
4X MTO	D13490675
4X MTO	D13637344

Benefits, Features & Applications

Features:

Tychem® 10000 exhibits excellent chemical barrier properties and offers an extremely durable fabric that is puncture- and tear-resistant. Tychem® 10000 fabric shows at least 30 minutes of barrier protection to 322 challenge chemicals with no observed breakthrough.

Applications:

Tychem® 10000 is specifically developed for protection against toxic, corrosive gases, liquids and solid chemicals. This high-performance chemical barrier fabric is suited for industrial, HazMat, and domestic preparedness applications.

Benefits:

Encapsulated Level A garment design is our highest level of protection from liquid splash and vapor/gas exposures for both the wearer and respiratory equipment
Double taped seams provide strong chemical resistance against heavy liquid splashes. A sewn seam is covered, both inside and outside of garment with compatible chemical-resistant material by heat-sealing.
Expanded anti-fog faceshield provides wide 220 degree viewing angle. EX faceshield is three-layer laminate composed of 40 mil PVC/5 mil Teflon™ / 20 mil PVC
Front entry design allows wearer to partially don garment (maintain standby position) without assistance
Expanded back to accommodate self-contained air breathing apparatus (SCBA)
Vapor tight zipper. Extra long to increase garment opening and aid donning and doffing
Storm flap covers zipper which can be secured by the wearer with rugged hook and loop material to prevent intrusion at zipper
Attached internal gloves composed of five layer laminate film for a broad range of chemical protection
Butyl gloves provide mechanical and physical durability to help protect inner glove. Gloves are attached with vapor tight ring and clamp system and are replaceable.
Integrated socks composed of garment material
Attached flaps are designed to cover boot tops to help reduce potential for liquid intrusion
Two exhaust valves release higher pressure inside encapsulating garments while simultaneously helping to prevent inward leakage of external vapors or particles into the garment. One-way valves are positive pressure and open on demand. Valves include splash covers made of barrier material to help prevent liquid intrusion. Valves are located on left back of head and right lower back. (146)
Internal adjustable waist belt system for support and improved fit
Additional barrier material sewn at knees and over taped for added abrasion resistance when kneeling or crawling
Each suit has a unique serial number and is fully tested at time of manufacture including positive air pressure integrity testing per ASTM F1052.
Manufactured under specifications that do not contain natural rubber latex.
Pass-thrus are optional and can be installed upon request when ordering. Some suits are available with optional pass-thrus to accommodate the following SCBA manufacturers: Scott, Interspiro, MSA, Draeger, Survivair®. Please call Customer Service 1-800-931-3456 for additional information. (3377)
Made in the USA, North American Free Trade Agreement (NAFTA) compliant and Trade Agreement Act (TAA) compliant

Selling Tips

Tychem® 10000

Premium protection against toxic and corrosive gas, liquid and solid chemicals as well as chemical warfare agents
Leading garment chosen by hazmat responders worldwide for CBRN response
Extremely durable, puncture- and tear-resistant fabric
Wide range of garment styles, including totally encapsulated, vapor protective Level A and liquid-splash protective Level B suits
Provides at least 30 minutes of protection against >320 chemicals
Tychem® TK612T/613T certified to NFPA 1994 Class 2
Lime yellow for high visibility
Encapsulated Tychem® 10000 suits are shipped in a storage tote with a color-coded handle: • Red handle = Level A • Silver handle = certified Level A • Blue handle = Level B • Yellow handle = training
