DuPont™ Tychem® 10000
TK612T LY

DuPont™ Tychem® 10000 Encapsulated Level A Suit. The highest level of protection against liquid splash and vapor/gas exposure with an extremely durable, puncture-resistant fabric. Lime yellow suit features an expanded back, front entry, an extra-wide, anti-fog, three-layer faceshield (40 mil PVC / 5 mil Teflon™ / 20 mil PVC), attached dual layer gloves (internal: multi-layer laminate / external: neoprene), attached socks with outer boot flaps, a double storm flap with hook and loop closure, two exhaust valves, and double taped seams. Certified to NFPA 1990 (NFPA 1994, Class 2) 2022 edition. Suitable for protection against toxic and corrosive substances in industrial, chemical handling, and emergency response applications.Quantity/box: 1 per case

Fit in a Range

Download Master File

Selling Tips

Media, web, pictures & literature

Product Info & Wear Trials

Click circles to show off details

More Technical Information and datasheet

Catalogues & Codes

Reference:

SKU	Size	D-code	Option Code
TK612TLYXS000100	XS	D14291703	Standard
TK612TLYMD00017W	MD	D15352383	(p/t) Interspiro with Hansen Fitting
TK612TLYMD00017N	MD	D15222966	(p/t) MSA Quick fill #80311 (right side) w/ cover
TK612TLYMD00017S	MD	D13638439	(p/t) Scott® #803620-01 w/ Hansen fitting (right side)
TK612TLYLG00017W	LG	D15352397	(p/t) Interspiro with Hansen Fitting
TK612TLYLG00017N	LG	D15222970	(p/t) MSA Quick fill #80311 (right side) w/ cover
TK612TLYLG00017S	LG	D13638413	(p/t) Scott® #803620-01 w/ Hansen fitting (right side)
TK612TLYXL00017N	XL	D15518537	(p/t) MSA Quick fill #80311 (right side) w/ cover
TK612TLYXL00017S	XL	D13492083	(p/t) Scott® #803620-01 w/ Hansen fitting (right side)
TK612TLY2X00017S	2X	D13491990	(p/t) Scott® #803620-01 w/ Hansen fitting (right side)
TK612TLY2X00017N	2X	D15518538	(p/t) MSA Quick fill #80311 (right side) w/ cover
TK612TLY3X00017N	3X	D15518539	(p/t) MSA Quick fill #80311 (right side) w/ cover
TK612TLY3X00017S	3X	D13492010	(p/t) Scott® #803620-01 w/ Hansen fitting (right side)
TK612TLY3X000100	3X	D13492008	Standard
TK612TLY4X00017N	4X	D15518540	(p/t) MSA Quick fill #80311 (right side) w/ cover
TK612TLY4X00017S	4X	D13638392	(p/t) Scott® #803620-01 w/ Hansen fitting (right side)
TK612TLY5X000100	5X	D14814972	Standard
TK612TLY6X000100	6X	D15574701	Standard

Benefits, Features & Applications

Features:

Tychem® 10000 exhibits excellent chemical barrier properties and offers an extremely durable fabric that is puncture- and tear-resistant. Tychem® 10000 fabric shows at least 30 minutes of barrier protection to 322 challenge chemicals with no observed breakthrough.

Applications:

Tychem® 10000 is specifically developed for protection against toxic, corrosive gases, liquids and solid chemicals. This high-performance chemical barrier fabric is suited for industrial, HazMat, and domestic preparedness applications.

Benefits:

Certified to NFPA 1990 (NFPA 1994, Class 2) 2022 edition
Class 2 garments are designed for situations where there is an immediate danger to life and health (IDLH) and must be worn with a self-contained breathing apparatus (SCBA).
Encapsulated Level A garment design is our highest level of protection from liquid splash and vapor/gas exposures for both the wearer and respiratory equipment
Double taped seams provide strong chemical resistance against heavy liquid splashes. A sewn seam is covered, both inside and outside of garment with compatible chemical-resistant material by heat-sealing.
Expanded anti-fog faceshield provides wide 220 degree viewing angle. EX faceshield is three-layer laminate composed of 40 mil PVC / 5 mil Teflon™ / 20 mil PVC
Front entry design allows wearer to partially don garment (maintain standby position) without assistance
Expanded back to accommodate self-contained air breathing apparatus (SCBA)
Vapor tight zipper. Extra long to increase garment opening and aid donning and doffing
Storm flap covers zipper which can be secured by the wearer with rugged hook and loop material to prevent intrusion at zipper
Attached internal gloves composed of five layer laminate film for a broad range of chemical protection
Neoprene gloves provide mechanical and physical durability to help protect inner gloves
Integrated socks composed of garment material
Attached flaps are designed to cover boot tops to help reduce potential for liquid intrusion
Two exhaust valves release higher pressure inside encapsulating garments while simultaneously helping to prevent inward leakage of external vapors or particles into the garment. One-way valves are positive pressure and open on demand. Valves include splash covers made of barrier material to help prevent liquid intrusion. Valves are located on left back of head and right lower back. (146)
Internal adjustable waist belt system for support and improved fit
Each suit has a unique serial number and is fully tested at time of manufacture including positive air pressure integrity testing per ASTM F1052.
Manufactured under specifications that do not contain natural rubber latex
Pass-thrus are optional and can be installed upon request when ordering. Some suits are available with optional pass-thrus to accommodate the following SCBA manufacturers: Scott, Interspiro, MSA, Draeger, Survivair®. Please call Customer Service 1-800-931-3456 for additional information. (3377)
Made in the USA, North American Free Trade Agreement (NAFTA) compliant and Trade Agreement Act (TAA) compliant

Selling Tips

Tychem® 10000

Premium protection against toxic and corrosive gas, liquid and solid chemicals as well as chemical warfare agents
Leading garment chosen by hazmat responders worldwide for CBRN response
Extremely durable, puncture- and tear-resistant fabric
Wide range of garment styles, including totally encapsulated, vapor protective Level A and liquid-splash protective Level B suits
Provides at least 30 minutes of protection against >320 chemicals
Tychem® TK612T/613T certified to NFPA 1994 Class 2
Lime yellow for high visibility
Encapsulated Tychem® 10000 suits are shipped in a storage tote with a color-coded handle: • Red handle = Level A • Silver handle = certified Level A • Blue handle = Level B • Yellow handle = training
